BSPT – JIC Adaptor
| Volz | Article No | Dash |
|---|---|---|
| 124201 | 7/16 JIC X 1/8 BSPT | -4-2 |
| 124202 | 7/16 JIC X 1/4 BSPT | -4-4 |
| 124206 | 7/16 JIC X 3/8 BSPT | -4-6 |
| 215490 | 7/16 JIC X 1/2 BSPT | -4-8 |
| 215491 | 1/2 JIC X 1/8 BSPT | -5-2 |
| 124203 | 1/2 JIC X 1/4 BSPT | -5-4 |
| 215492 | 1/2 JIC X 3/8 BSPT | -5-6 |
| 215493 | 9/16 JIC X 1/8 BSPT | -6-2 |
| 124204 | 9/16 JIC X 1/4 BSPT | -6-4 |
| 124207 | 9/16 JIC X 3/8 BSPT | -6-6 |
| 124210 | 9/16 JIC X 1/2 BSPT | -6-8 |
| 124213 | 9/16 JIC X 3/4 BSPT | -6-12 |
| 124205 | 3/4 JIC X 1/4 BSPT | -8-4 |
| 124208 | 3/4 JIC X 3/8 BSPT | -8-6 |
| 124211 | 3/4 JIC X 1/2 BSPT | -8-8 |
| 215494 | 3/4 JIC X 3/4 BSPT | -8-12 |
| 124209 | 7/8 JIC X 3/8 BSPT | -10-6 |
| 124212 | 7/8 JIC X 1/2 BSPT | -10-8 |
| 215495 | 7/8 JIC X 3/4 BSPT | -10-12 |
| 200859 | 1.1/16 JIC X 1/2 BSPT | -12-8 |
| 124214 | 1.1/16 JIC X 3/4 BSPT | -12-12 |
| 124216 | 1.1/16 JIC X 1 BSPT | -12-16 |
| 215496 | 1.5/16 JIC X 1/2 BSPT | -16-8 |
| 124215 | 1.5/16 JIC X 3/4 BSPT | -16-12 |
| 124217 | 1.5/16 JIC X 1 BSPT | -16-16 |
| 124218 | 1.5/16 JIC X 1.1/4 BSPT | -16-20 |
| 215497 | 1.5/16 JIC X 1.1/2 BSPT | -16-24 |
| 215498 | 1.5/8 JIC X 1 BSPT | -20-16 |
| 124219 | 1.5/8 JIC X 1.1/4 BSPT | -20-20 |
| 215499 | 1.5/8 JIC X 1.1/2 BSPT | -20-24 |
| 215500 | 1.7/8 JIC X 1.1/4 BSPT | -24-20 |
| 212692 | 1.7/8 JIC X 1.1/2 BSPT | -24-24 |
| 212693 | 2.1/2 JIC X 2 BSPT | -32-32 |
